KFH146U/74 -Black metal finish, 13amp UK socket and Cat6 data – Manual twist lock

KFH146U/74 – Black single top section with manual twist lid lock. Internally the unit has a 13amp socket and a Cat6 data module. The top section must be used with either the screed back box (KGT100/74) or cavity floor back box (KGT100RF/74)
The sleek black finish designed to complement a wide scope of floor finishes. The manual opening/closing lock allows easy access to the sockets. When in use, the lid is anchored in a partially open position. When closed the lid sits seamlessly flush with the surrounding floor surface.
The Simon-Box is installed in a wide range of projects and is an ideal choice for areas which would benefit from in floor power that require to be occasionally wet washed. Project examples include Airport concourse areas, retail and car showrooms, hotels, stadiums and private homes.

The KFH146U/74 single top section is designed in accordance with the safety requirements of Directive 2006/95/CE (Low Voltage) through compliance with UNE-EN standard 60.670. CE and UKCA marked. The manual locked top section is supplied with 1no 13amp unswitched sockets and a Cat6 data module.

Closed Box	Open Box
-IP66 Protection Grade	-IP20 Protection Grade (IP54 with accessory)
-IK08 Impact Protection Grade	– IK07 Impact Protection Grade
-Maximum weight per area unit: 12kg/cm2	-Maximum weight per area unit: 4kg/cm2
-Maximum total weight – 1500kg	-Maximum total weight – 250kg
