The KFH100SEC/72 single brush stainless steel top section is designed in accordance with the safety requirements of Directive 2006/95/CE (Low Voltage) through compliance with UNE-EN standard 60.670. CE and UKCA marked. The security locked top section is supplied with a 13amp unswitched sockets and a 22.5 x 45mm blank space module.
| Closed Box | Open Box |
| -IP66 Protection Grade | -IP20 Protection Grade (IP54 with accessory) |
| -IK08 Impact Protection Grade | – IK07 Impact Protection Grade |
| -Maximum weight per area unit: 12kg/cm2 | -Maximum weight per area unit: 4kg/cm2 |
| -Maximum total weight – 1500kg | -Maximum total weight – 250kg |
A 6mm Allen key lock prevents unauthorised access to the floor outlet. When in use, the lid is supported by a sprung metal pedestal bracket which holds the lid in a partially open position. Note when open the unit is IP20 rated. The back box is supplied with drainage options. Fitting instructions should be fully followed.
Overall Dimensions:
Screed Type –Â 115mm x 115mm
Cavity Type – 148mm x 148mm
Overall depth – 80mm
