KFH100/74 – Black Metal Finish -Empty Power and data spaces – Manual Twist/turn lock

KFH100/74 – Black single top section with manual lid lock. Internally the unit has 1no. unpopulated 45mm x 45mm and 1no. 22.5mm x 45mm openings to accept K45 socket inserts for a custom socket configuration. Select from 13amp UK, 5amp UK, Schuko, US110v, USB Charger and Cat5 or Cat6 data. The top section must be used with either the screed back box (KGT100/74) or cavity floor back box (KGT100RF/74)
The sleek black finish designed to complement a wide scope of floor finishes. The manual twist opening/closing lock allows easy access to the sockets. When in use, the lid is anchored in a partially open position.

The Simon-Box is installed in a wide range of projects and is an ideal choice for areas which would benefit from in floor power that require to be occasionally wet washed. Project examples include Airport concourse areas, retail and car showrooms, hotels, stadiums and private homes.

The KFH100/74 top section is designed in accordance with the safety requirements of Directive 2006/95/CE (Low Voltage) through compliance with UNE-EN standard 60.670. CE and UKCA marked.
The manual locked top section has 1no unpopulated 45mm x 45mm and 1no. 22.5mm x 45mm module openings for custom population.

Closed Box	Open Box
-IP66 Protection Grade	-IP20 Protection Grade (IP54 with accessory)
-IK08 Impact Protection Grade	– IK07 Impact Protection Grade
-Maximum weight per area unit: 12kg/cm2	-Maximum weight per area unit: 4kg/cm2
-Maximum total weight – 1500kg	-Maximum total weight – 250kg

The top section sits flush within the back box. The single top section dimensions are 114mm x 114mm. The screed back box measures 115mm x115mm x 81mm. The raised floor back box features a brush stainless steel flange measuring 148mm x 148mm and fits an opening 125mm x 125mm.

Overall Dimensions:

Screed Type – 115mm x 115mm

Cavity Type – 148mm x 148mm

Overall depth – 80mm
